FM Mattsson tronic compact WMS, with thermostatic function, battery operation

Find retailers
Description
Chrome, battery operation, included battery, excluded mounting plate
Article number
95177000
GTIN
7391887251504

PROPERTIES

  • Tronic Copmpact with possibilities of wireless connection
  • Thermostatic function, with adjustable temperature
  • Battery operation, can be converted to mains operation
  • Connection at the back, connection are ordered separately
  • Solenoid valve, shut-off valve and electronics integrated in the shower head
  • Programmable start button. Rinsing time from 10–60 seconds, (30 seconds is the factory preset)
  • Flush Timeout - safety shut-off to prevent flooding, maximum of 5 minutes
  • Jet angle adjustable +/- 5°
  • Flow limiter 9 l/min
  • Can be turned off by solenoid valve (eg for cleaning)
  • Low power consumption - Long life
  • Equipped with function for thermal disinfection against legionella
  • IP class sensor, IP67
  • Approved non-return valves, EN-Standard EN1717

    Installation:
  • The power cable between the shower head and the start button should ideally be placed in the joints between wall tiles or in a pipe, but take care not to damage the wall’s moisture barrier
  • Mains operation requires installation of the AC adapter FMM S600131, and power supply FMM S600129 alternatively transformer FMM S600128, plus extension cable FMM S600127

    Tronic WMS:
  • With wireless connection to the Tronic WMS system (gateway and subscription required) alternatives via Dongel (729482) the following opportunities are obtained:
    - Programmable rinsing time from 10–60 seconds
    - Built-in temperature measurements (measures output water temperature)
    - Programmable temperature stop, the mixer will turn off directly at set maximum temperature
    - Flush time control, prevents overflow, maximum flush time 5 min.
    - Adjustable hygiene flushing, interval and flush time (to prevent water becoming stagnant)
    - Logging of all flushings with point of time, water consumption and temperature. - Only with WMS
    - Alarm via SMS or email – Only with WMS
K Tronic compact WMS.jpg
No. FMM No. RSK Description
1 28145000 8221805 Connectors, complete
2 28145100 8221807 Connector, complete
3 28141000 8221803 Mounting plate with connection for CU 12-15 and PEX 15
4 28141600 8221804 Mounting plate with connection for PEX 16, ALU-PEX 16
5 19451550 8221801 Coupling kit, PEX 15
6 19451250 8221799 Gasket kit, CU 12
7 19451500 8221800 Gasket kit, CU 15
8 19451600 8221802 Coupling kit, PEX 16
9 38147000 8221811 Thermostatic cartridge
10 16202000 8221794 Solenoid valve
11 16216600 8221793 Electronic unit
12 S600135 8483191 Battery
13 S600131 8483190 AC adapter
14 29182000 8221808 Shower strainer

modal.bvb.desc;

Accepted installation instructions

Safe Water Installation (Säker Vatteninstallation) is a set of industry* regulations to safeguard the quality of sanitary installations, prevent injury and damage and ensure compliance with the building regulations of the Swedish National Board of Housing, Building and Planning (Boverket).

Leadfree

Lead Free means that we have eliminated the lead that is normally found in brass alloys. This will reduce environmental impact of the products. Products classified as Lead Free contain less than 0.1 % lead.

Energyclass

Energy labelling is an objective rating system that shows exactly how much energy a mixer uses. The system was developed by a number of players including sanitary fittings manufacturers, building companies, property owners and authorities such as the Swedish Energy Agency. It is based on standardised laboratory tests and certification rules. Its aim is simple: to offer impartial help for buyers, installation firms, air conditioning consultants and consumers. The mixer’s energy performance is assessed by measuring and registering water pressure, mixed water temperature and flushing time for twelve different activities. The values registered for each of these activities are added together to obtain a total energy consumption value, which is displayed on the label. This total value determines the mixer’s energy rating.
