9000XE rinse mixer
Designed to meet the demanding requirements of professional kitchens, this mixer combines a sleek, durable design with materials that are easy to clean and keep hygienic. It is completely lead-free and equipped with easy-grip handles as well as a built-in diverter function that makes it simple to switch between the spout and the flexible spray nozzle.
The mixer responds quickly to changes in pressure and temperature, ensuring a consistent and safe water temperature. The automatic hot-water lock also provides complete scald protection. Delivered with a 10-year 9000XE functional guarantee for extra peace of mind in everyday use.
PROPERTIES
- Pressure balanced thermostatic mixer
- Temperature handle with safety stop 38°C
- With Eco-function
- Lead Free material
- With approved non-return valves, EN-Standard EN1717
- With swivel spout, length 350 mm
- With care-handle
Backflow protection unit type
Enter your e-mail address, then the parts list will be sent to your inbox.
| No. | FMM No. | RSK | Description |
|---|---|---|---|
| 1 | S600083 | 8218917 | On/off handle, complete, krom |
| 2 | S600116 | 8218920 | End cover, chrome |
| 3 | S600082 | 8218914 | Temperature handle, complete, chrome |
| 4 | S600021 | 8441463 | Reversible headwork 22 l/min, with service tool |
| 4 | S600270 | 8387233 | Reversible headwork 22 l/min |
| 5 | S600117 | 8439714 | Stop ring, for two outlet (down and up) |
| 6 | S600087 | 8439711 | Scalding protection ring, max 50°C |
| 7 | S600084 | 8439709 | Thermostatic cartridge, complete, incl. service tool |
| 7 | S600271 | 8397030 | Thermostatic cartridge, complete, without service tool |
| 8 | S600088 | 8439712 | Nipple M18x1–G1/2 for shower mixer |
| 9 | 35861350 | 8242308 | Spout, L=350 mm, 11–15 l/min at 300 kPa |
| 10 | 59800800 | 8592005 | Inlet connectors, 160 c/c |
| 11 | 38632006 | 8590311 | Filter |
| 12 | S600105 | 8439713 | Care-handle, black, 2 pcs |
modal.bvb.desc;
Accepted installation instructions
Safe Water Installation (Säker Vatteninstallation) is a set of industry* regulations to safeguard the quality of sanitary installations, prevent injury and damage and ensure compliance with the building regulations of the Swedish National Board of Housing, Building and Planning (Boverket).
Leadfree
Lead Free means that we have eliminated the lead that is normally found in brass alloys. This will reduce environmental impact of the products. Products classified as Lead Free contain less than 0.1 % lead.
Energyclass
Energy labelling is an objective rating system that shows exactly how much energy a mixer uses. The system was developed by a number of players including sanitary fittings manufacturers, building companies, property owners and authorities such as the Swedish Energy Agency. It is based on standardised laboratory tests and certification rules. Its aim is simple: to offer impartial help for buyers, installation firms, air conditioning consultants and consumers. The mixer’s energy performance is assessed by measuring and registering water pressure, mixed water temperature and flushing time for twelve different activities. The values registered for each of these activities are added together to obtain a total energy consumption value, which is displayed on the label. This total value determines the mixer’s energy rating.
