ORIGO shower mixer

Origo mixers combine creative visual design with practical functions for safe, ergonomic use. All the control knobs are rubber-coated, making them easy to grip and use. Pleasing to the eye – comfortable for the hand. Accurate temperature and pressure control guarantees unbeatable shower comfort.
Find retailers
Description
Chrome
Article number
94801530
GTIN
7319049480029

PROPERTIES

  • With shower connection down
  • Pressure balanced thermostatic mixer
  • Temperature handle with safety stop at 38°C
  • Approved non-return valves, EN-Standard EN1717
Backflow protection unit type EB
K Origo Säkerhetsblandare 160cc och 150cc och 40cc.jpg
No. FMM No. RSK Description
1 35460000 8591514 On/off handle, chrome
2 35201400 8585846 On/off headwork with valve cone
3 36001500 8913411 Valve cone
3 36001549 8913436 Valve cone, 10 pcs
4 38601009 8591609 Thermostatic cartridge, complete, incl. service tool
5 38680009 8591701 Filter kit incl. o-rings and service tool
6 38520007 8591592 Scalding protection ring, standard (black)
7 35470000 8591515 Temperature handle, chrome
8 59800000 8591543 Inlet connectors, 160 c/c
8 59810000 8591544 Inlet connectors 150-153 c/c (left-handed thread)
9 29830529 8591702 Non-return valves, 2 pcs
10 39710000 8591571 Nipple M22x1-G1/2 for shower mixer
11 39753000 8591516 Nipple for spout
12 38086000 8439701 Locking screw
13 29030000 8242087 Aerator M28 ext., 24–26 l/min at 300 kPa
14 29712000 8591530 Wall bracket for 40 c/c mixers, complete
15 59820000 8591545 Inlet connector for 40 c/c mixer
16 38521000 8295345 Stop ring

modal.bvb.desc;

Accepted installation instructions

Safe Water Installation (Säker Vatteninstallation) is a set of industry* regulations to safeguard the quality of sanitary installations, prevent injury and damage and ensure compliance with the building regulations of the Swedish National Board of Housing, Building and Planning (Boverket).

Leadfree

Lead Free means that we have eliminated the lead that is normally found in brass alloys. This will reduce environmental impact of the products. Products classified as Lead Free contain less than 0.1 % lead.

Energyclass

Energy labelling is an objective rating system that shows exactly how much energy a mixer uses. The system was developed by a number of players including sanitary fittings manufacturers, building companies, property owners and authorities such as the Swedish Energy Agency. It is based on standardised laboratory tests and certification rules. Its aim is simple: to offer impartial help for buyers, installation firms, air conditioning consultants and consumers. The mixer’s energy performance is assessed by measuring and registering water pressure, mixed water temperature and flushing time for twelve different activities. The values registered for each of these activities are added together to obtain a total energy consumption value, which is displayed on the label. This total value determines the mixer’s energy rating.
