MEDICARE kitchen mixer
MEDICARE kitchen mixer is designed for professional kitchens. The ergonomic lever is easy to operate with the whole hand and provides good control even for users with reduced hand function. The low spout is compact, easy to control and reduces the risk of splashing. An ideal solution where space is limited.
A choice between PEX or copper connections offers flexibility during installation and makes it easy to tailor the solution to specific project requirements.
About the collection
MEDICARE is FM Mattsson’s range of products for healthcare and care settings with high requirements for hygiene, safety and accessibility. The products are made from lead-free brass and combine a construction designed for easy cleaning with well-thought-out design, ergonomic controls and safe temperature settings.
With a 10-year spare parts guarantee, Medicare is a reliable, long-term choice for professional installations.
- Description
- Chrome, connection nut G3/8"
- Article number
- 32404010
- RSK
- 8312436
- EAN
- 7391887275364
- Flow 3 bar
- 6.0 l/m
PROPERTIES
- Cold Start
- Ceramic cartridge with soft closing function
- Adjustable flow control and temperature limiter
- Eco Flow (energy and water saving aerator)
- Swivel spout 110°
- Lever: 180 mm
- Soft PEX® hoses with 3/8" connecting nut (stainless steel braided)
- Lead Free material
- Hole diameter Ø34-37 mm
| No. | FMM No. | RSK | Description |
|---|---|---|---|
| 1 | S600062 | 8394130 | Lever, complete, L=190 mm |
| 2 | 58530160 | 8241727 | Fastening nipple for cartridge, incl. service tool |
| 3 | S600298 | 3870203 | Service tool |
| 4 | S600273 | 8387230 | Ceramic cartridge with service tool, cold start (green ring) |
| 5 | 58660000 | 8592035 | Spout |
| 6 | 38080000 | 8241723 | Stop screw |
| 7 | S600301 | 8387255 | Sealing rings, 2 pcs |
| 8 | 38230005 | 8141730 | Limitation clapm for fixed spout and swivel 30-90° |
| 9 | 29142400 | 8281526 | Housing M24 ext., 13 mm |
| 10 | 29102910 | 8281534 | Aerator insert, 5,5–6,5 l/min at 300kPa |
| 11 | 39141000 | 8186888 | Fastening kit, for mixers without on/off valve |
modal.bvb.desc;
Accepted installation instructions
Safe Water Installation (Säker Vatteninstallation) is a set of industry* regulations to safeguard the quality of sanitary installations, prevent injury and damage and ensure compliance with the building regulations of the Swedish National Board of Housing, Building and Planning (Boverket).
Leadfree
Lead Free means that we have eliminated the lead that is normally found in brass alloys. This will reduce environmental impact of the products. Products classified as Lead Free contain less than 0.1 % lead.
Energyclass
Energy labelling is an objective rating system that shows exactly how much energy a mixer uses. The system was developed by a number of players including sanitary fittings manufacturers, building companies, property owners and authorities such as the Swedish Energy Agency. It is based on standardised laboratory tests and certification rules. Its aim is simple: to offer impartial help for buyers, installation firms, air conditioning consultants and consumers. The mixer’s energy performance is assessed by measuring and registering water pressure, mixed water temperature and flushing time for twelve different activities. The values registered for each of these activities are added together to obtain a total energy consumption value, which is displayed on the label. This total value determines the mixer’s energy rating.
